FEP-0311W90, 3-PORT FAST ETHERNET POE SWITCH, 2 POE OUTPUTS, 90W

Hãng: Level One

Mã sản phẩm: FEP-0311W90

Tình trạng: Còn hàng

Liên hệ

0978470323

- Xuất xứ: China

- Bảo hành: 24 tháng

Cho vào giỏ

Chính sách bán hàng

Bảo hành tại nơi sử dụng

Sửa chữa chi phí rẻ nhất

Miễn phí giao hàng

Cam kết hàng chính hãng 100%

- 2 cổng Fast Ethernet PoE và 1 cổng Fast Ethernet
- Tuân thủ IEEE 802.3af / at PoE để đơn giản hóa việc triển khai và cài đặt
- Kiểm soát luồng IEEE 802.3x bảo vệ khỏi các gói bị mất để truyền dữ liệu đáng tin cậy
- Bảo vệ nguồn: quá áp / quá dòng / quá nhiệt

FEP-0311 là Bộ chuyển mạch Fast Ethernet 3 cổng 10M / 100M. Một cổng uplink đang kết nối với bộ chuyển mạch LAN khác và 2 cổng có khả năng Power over Ethernet PSE. Với công tắc nhúng, mỗi cổng PoE có thể được đặt thủ công để điều khiển Bật-Tắt.

Approval and compliance	FCC Class B, CE EMI: EN55022:2010 Class B AS/NZS CISPR 22 Amdt. (2010) EN61000-3-2:2014 EN61000-3-3:2013 EMS: EN55024:2010 IEC61000-4-2:2008 IEC61000-4-3:2006+A1:2007+A2:2010 IEC61000-4-4:2012 IEC61000-4-5:2014 IEC61000-4-6:2013 IEC61000-4-8:2009 IEC61000-4-11:2004FCC Class B, CE EMI: EN55022:2010 Class B AS/NZS CISPR 22 Amdt. (2010) EN61000-3-2:2014 EN61000-3-3:2013 EMS: EN55024:2010 IEC61000-4-2:2008 IEC61000-4-3:2006+A1:2007+A2:2010 IEC61000-4-4:2012 IEC61000-4-5:2014 IEC61000-4-6:2013 IEC61000-4-8:2009 IEC61000-4-11:2004FCC Class B, CE EMI: EN55022:2010 Class B AS/NZS CISPR 22 Amdt. (2010) EN61000-3-2:2014 EN61000-3-3:2013 EMS: EN55024:2010 IEC61000-4-2:2008 IEC61000-4-3:2006+A1:2007+A2:2010 IEC61000-4-4:2012 IEC61000-4-5:2014 IEC61000-4-6:2013 IEC61000-4-8:2009 IEC61000-4-11:2004FCC Class B, CE EMI: EN55022:2010 Class B AS/NZS CISPR 22 Amdt. (2010) EN61000-3-2:2014 EN61000-3-3:2013 EMS: EN55024:2010 IEC61000-4-2:2008 IEC61000-4-3:2006+A1:2007+A2:2010 IEC61000-4-4:2012 IEC61000-4-5:2014 IEC61000-4-6:2013 IEC61000-4-8:2009 IEC61000-4-11:2004FCC Class B, CE EMI: EN55022:2010 Class B AS/NZS CISPR 22 Amdt. (2010) EN61000-3-2:2014 EN61000-3-3:2013 EMS: EN55024:2010 IEC61000-4-2:2008 IEC61000-4-3:2006+A1:2007+A2:2010 IEC61000-4-4:2012 IEC61000-4-5:2014 IEC61000-4-6:2013 IEC61000-4-8:2009 IEC61000-4-11:2004FCC Class B, CE EMI: EN55022:2010 Class B AS/NZS CISPR 22 Amdt. (2010) EN61000-3-2:2014 EN61000-3-3:2013 EMS: EN55024:2010 IEC61000-4-2:2008 IEC61000-4-3:2006+A1:2007+A2:2010 IEC61000-4-4:2012 IEC61000-4-5:2014 IEC61000-4-6:2013 IEC61000-4-8:2009 IEC61000-4-11:2004FCC Class B, CE EMI: EN55022:2010 Class B AS/NZS CISPR 22 Amdt. (2010) EN61000-3-2:2014 EN61000-3-3:2013 EMS: EN55024:2010 IEC61000-4-2:2008 IEC61000-4-3:2006+A1:2007+A2:2010 IEC61000-4-4:2012 IEC61000-4-5:2014 IEC61000-4-6:2013 IEC61000-4-8:2009 IEC61000-4-11:2004FCC Class B, CE EMI: EN55022:2010 Class B AS/NZS CISPR 22 Amdt. (2010) EN61000-3-2:2014 EN61000-3-3:2013 EMS: EN55024:2010 IEC61000-4-2:2008 IEC61000-4-3:2006+A1:2007+A2:2010 IEC61000-4-4:2012 IEC61000-4-5:2014 IEC61000-4-6:2013 IEC61000-4-8:2009 IEC61000-4-11:2004FCC Class B, CE EMI: EN55022:2010 Class B AS/NZS CISPR 22 Amdt. (2010) EN61000-3-2:2014 EN61000-3-3:2013 EMS: EN55024:2010 IEC61000-4-2:2008 IEC61000-4-3:2006+A1:2007+A2:2010 IEC61000-4-4:2012 IEC61000-4-5:2014 IEC61000-4-6:2013 IEC61000-4-8:2009 IEC61000-4-11:2004
Max. operating humidity (%)	90
Max. operating temperature (°C)	40
Max. storage humidity (%)	90
Max. storage temperature (°C)	70
Min. operating humidity (%)	10
Min. operating temperature (°C)	0
Min. storage humidity (%)	10
Min. storage temperature (°C)	-20
Backplane (Gbps)	10/100Mbps
Indicators	Power, Uplink, LAN 1~2 port, PoE 1~2 port
MAC address table	4K
Flash memory size	384
Mount	Desk mount
Power output	Per Port 56VDC, Max. 56 watts
Power switch	No
Processor	RTL8305NB
Standards	IEEE 802.3 10-BASE-T (Ethernet) IEEE 802.3u 100-BASE-TX (Fast Ethernet) IEEE 802.3x Flow Control (full-duplex flow control) IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet PlusIEEE 802.3 10-BASE-T (Ethernet) IEEE 802.3u 100-BASE-TX (Fast Ethernet) IEEE 802.3x Flow Control (full-duplex flow control) IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet PlusIEEE 802.3 10-BASE-T (Ethernet) IEEE 802.3u 100-BASE-TX (Fast Ethernet) IEEE 802.3x Flow Control (full-duplex flow control) IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet PlusIEEE 802.3 10-BASE-T (Ethernet) IEEE 802.3u 100-BASE-TX (Fast Ethernet) IEEE 802.3x Flow Control (full-duplex flow control) IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet PlusIEEE 802.3 10-BASE-T (Ethernet) IEEE 802.3u 100-BASE-TX (Fast Ethernet) IEEE 802.3x Flow Control (full-duplex flow control) IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet PlusIEEE 802.3 10-BASE-T (Ethernet) IEEE 802.3u 100-BASE-TX (Fast Ethernet) IEEE 802.3x Flow Control (full-duplex flow control) IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet PlusIEEE 802.3 10-BASE-T (Ethernet) IEEE 802.3u 100-BASE-TX (Fast Ethernet) IEEE 802.3x Flow Control (full-duplex flow control) IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet PlusIEEE 802.3 10-BASE-T (Ethernet) IEEE 802.3u 100-BASE-TX (Fast Ethernet) IEEE 802.3x Flow Control (full-duplex flow control) IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet PlusIEEE 802.3 10-BASE-T (Ethernet) IEEE 802.3u 100-BASE-TX (Fast Ethernet) IEEE 802.3x Flow Control (full-duplex flow control) IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus
Product weight (kg)	0,2
Product breadth (mm)	62
Product depth (mm)	90
Product height (mm)	27
Color	Grey
EAN	4015867203231
Model number	FEP-0311W90
Package contents	FEP-0311W90, Power Adapter, Power Cord, User Manual
Console RJ45	1
802.3af/at PoE	2
Switching capacity	0.6Gbps
Grade	Business
Data Rate	Fast Ethernet
PoE Supported	Yes
Switch Manageable	No
Fanless	Yes
Switch Concurrent ports	3.00 Ports
